QP-200-3A

Name: QP-200-3A
Brand: MEAN WELL
Price: 112.58 USD
Availability: OutOfStock

$112.58

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$106.95

20+

$104.70

50+

$102.45

100+

$100.20

200+

$97.94

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

Rated Current

15A

Power Rating

200W

Waterproof

Non-waterproof

Dimensions

8.46 x 4.52 x 1.96 in

Weight

2.64 lbs

Features

Protections: Short circuit / Overload / Over voltage

Built-in active PFC function, PF>0.95

Universal AC input/Full range

Cooling by built-in DC fan

High operating temperature up to 60°C

Built-in remote sense function for CH1,2

Fixed switching frequency at 100KHz

High efficiency, long life and high reliability

3 years warranty

General Specification

AC input voltage range	90~264VAC, 127~373VDC
AC inrush current (max.)	50A at 230VAC
DC adjustment range	±10% by potentiometer for CH1, CH2
Overload protection	110%~150%
Over voltage protection	115%~135% rated output voltage, hiccup mode, auto-recovery
Withstand voltage	I/P - O/P: 3KVAC, I/P - FG: 2KVAC, O/P - FG: 0.5KVAC
Working temperature	-10~+60°C
Vibration	10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes
Safety standards	UL60950-1, TUV EN60950-1 approved
EMC standards	EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection	Terminal block for input and output
Dimension (LxWxH)	215x 115x 50
Case No.	912B
Packing	12pcs /15.4kg
