XLG-320-48-ABV

Name: XLG-320-48-ABV
Brand: MEAN WELL
SKU: 025-150
Price: 127.43 USD
Availability: OutOfStock

$127.43

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$121.06

20+

$118.51

50+

$115.96

100+

$113.41

200+

$110.86

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

48V

Rated Current

6.5A

Power Rating

312W

Waterproof

IP67

Dimensions

9.68 x 3.03 x 1.55 in

Weight

3.19 lbs

Features:

Wide input range 100~305V AC(Class I)
Full power output at 75~100% Constant power mode operation
Metal case with IP67, suitable for outdoor application
Surge protection with 6KV/4KV
3-in-1 Dimming (Dim-to-off and Isolation design)
Protection functions: OLP / SCP / OVP / OTP
Compliance to EN60335-1 household application
Lifetime >50,000 hrs
5 years warranty

General Specification

AC input voltage range

100 ~ 305VAC 142VDC ~ 431VDC

(Please refer to "STATIC CHARACTERISTIC" )

AC inrush current (max.)

COLD START 45A(twidth=1200μs measured at 50% Ipeak) at 230VAC; Per NEMA 410

Over-voltage protection

350 ~ 380V | 190 ~ 220V | 63 ~ 78V | 27 ~ 34V

(Shut down output voltage, re-power on to recovery)

Withstand voltage

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC

Working temperature

Tcase = -40 ~ +85℃ (Please refer to "OUTPUT LOAD vs TEMPERATURE" section)

Safety standards

UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, EN/EN60335-1 compliant to EN 60335-2-89 Annex BB, EN 60335-2-24 Annex CC;GB19510.1, GB19510.14;EAC TP TC 004; IP67; IS15885(Part2/Sec13)(except for blank type), KC61347-1,KC61347-2-13 approved

Dimension (LxWxH)

246x77x39.5mm

Environmental Documents
