HEP-1000-24

Name: HEP-1000-24
Brand: MEAN WELL
Price: 411.78 USD
Availability: OutOfStock

$411.78

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$391.19

20+

$382.96

50+

$374.72

100+

$366.48

200+

$358.25

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

24V

Rated Current

42A

Power Rating

1008W

Waterproof

IP67

Dimensions

12.20 x 5.66 x 1.90 in

Weight

8.81 lbs

Datasheet (PDF)

Open PDF

If the PDF doesn’t load here, click “Open PDF”.

Features

Universal AC input (up to 305VAC) / Full range

High efficiency up to 96%

Built-in active PFC function

Protections: Short circuit / Over current / Over voltage / Over temperature

IP67 design for indoor or outdoor installation

Cooling by free air convection

DC OK active signal and 12V Auxiliary power available

Aluminum case and filling with heat-conducted glue

Withstand 10G vibration test

Operating altitude up to 5000 meters

6 years warranty

General Specification

AC input voltage range	90~305VAC ; 250~431VDC
AC inrush current (max.)	Cold start, 40A at 230VAC
DC adjustment range	-10%~+10% rated output voltage (A-Type only)
Current adjustment range	50%~100%
Over current protection	105%~125% constant current limiting, auto-recovery
Over voltage protection	105%~135% rated output voltage
Setup, rise, hold up time	1800ms, 80ms, 16ms at full load and 230VAC
Withstand voltage	I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC
Working temperature	-40~+70ºC (refer to output derating curve)
Safety standards	UL60950-1, TUV EN60950-1 approved
EMC standards	EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection Input	3+7P / 11mm pitch terminal block with cover
Connection Output	W-Type:SJTW 16AWGx2C (30cm)+ SJTW 14AWGx2C (30cm)+ AWM 24AWGx6C(35cm)
Dimension (LxWxH) (mm)	310x 144x 48.5
