SE-1000-15

Name: SE-1000-15
Brand: MEAN WELL
Price: 171.86 USD
Availability: OutOfStock

$171.86

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$163.27

20+

$159.83

50+

$156.39

100+

$152.96

200+

$149.52

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

15V

Rated Current

66.7A

Power Rating

1000.5W

Waterproof

Non-waterproof

Dimensions

10.94 x 5 x 2.5 in

Weight

5.51 lbs

Datasheet (PDF)

Open PDF

If the PDF doesn’t load here, click “Open PDF”.

Features

AC input selectable by switch

100% full load burn-in test

LED indicator for power on

Built-in remote sense function

Forced air cooling by built-in DC fan

Protections: Short circuit / Overload / Over voltage / Over temperature

DC OK, remote ON/OFF control

2 years warranty

General Specification

AC input voltage range	90~132VAC / 180~264VAC selected by switch (600~1000W)
AC inrush current (max.)	Cold start, 55A at 230VAC
DC adjustment range	±10% rated output voltage
Overload protection Range	105%~125%
Overload protection Type	Shut down o/p voltage, re-power on to recover
Over voltage protection	115%~145%
Withstand voltage	I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, 1 minute
Working temperature	-20~+60°C (refer to output derating curve)
Safety standards	UL60950-1 approved
EMC standards	Design refer to EN55022 class B
Connection	Terminal block with cover for input and output (SE-1000/1500: copper pillars for output)
Dimension (LxWxH)	278x 127x 63.5
Case No.	935B
Packing	6pcs / 16kg
