RST-10000-36

Name: RST-10000-36
Brand: MEAN WELL
Price: 2978.87 USD
Availability: OutOfStock

$2,978.87

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$2,829.93

20+

$2,770.35

50+

$2,710.77

100+

$2,651.19

200+

$2,591.62

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

36V

Rated Current

276A

Power Rating

9936W

Waterproof

Non-waterproof

Dimensions

21.25 x 16.69 x 3.28 in

Weight

51.80 lbs

Datasheet (PDF)

Open PDF

If the PDF doesn’t load here, click “Open PDF”.

Features

wide input range

Built-in active PFC function

Protections: Short circuit / Overload / Over voltage / Over temperature / Fan alarm

High efficiency up to 91%

Built-in fan speed control

High efficiency up to 91%

Built-in remote sense and ON/OFF control

Built-in 12V/0.1A auxiliary power

5 years warranty

General Specification

AC input voltage range	3 3-wire/ 196~305VAC or 3 4-wire/ Y 340~530VAC
AC inrush current (max.)	Cold start, 50A (RST-5000); 100A(RST-10000) at 400VAC(3 4-wire/Y) 75A(RST-5000); 150A(RST-10000) at 230VAC (3 3-wire/ )
DC adjustment range	-2%~+20% rated output voltage
Overload protection Range	100%~112% constant current limiting,
Overload protection Type	auto-recovery (can adjust to delay shut off)
Over voltage protection Range	125%~140%
Over voltage protection Type	Shut down O/P voltage, re-power on to recover
Withstand voltage	I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature	-30~+70°C (refer to output derating curve)
Safety standards	UL60950-1, TUV EN60950-1, CCC GB4943 approved
EMC standards	EN55022 class A, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
