NLDD-1400H

Name: NLDD-1400H
Brand: MEAN WELL
Price: 6.43 USD
Availability: OutOfStock

$6.43

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$6.11

20+

$5.98

50+

$5.85

100+

$5.72

200+

$5.59

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

46V

Rated Current

1.4A

Power Rating

60W

Waterproof

Non-waterproof

Dimensions

1.26 x 0.80 x 0.49 in

Weight

0.03 lbs

Features

DC/DC step-down converter

Constant current output: 350mA to 1400mA

Wide input voltage: 10~56VDC(59VDC Max.)

Wide output LED forward voltage: 6~52VDC

High efficiency up to 96%

Comply with BS EN/EN61347 and BS EN/EN55015 regulation

Build-in PWM and remote ON/OFF control

Protections: Short circuit/Over temperature

Cooling by free air convection

Fully encapsulated and compact size

Suitable for driving illumination LED

3 years warranty

General Specification

Current accuracy	±5% at 48V
Over temperature protection	Protection type : Shut down, recovers automatically after temperature goes down
Efficiency	96% at full load and 36VDC/48VDC input
Short circuit protection	Regulated at rated output current
Working temperature	-40°C to +50°C
EMC	Compliance to EN55015 class B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Temp. Coefficient	±0.03% / °C
Dimension (LxWxH) (mm)	32.120.512.5mm or 1.26"0.8"0.49" inch
Potting material	Epoxy
