MDD06G-05

$15.58
Availability: Out of stock
ℹ️ Lead time for quantities greater than shown, contact us
Quantity Prices
Quantity
Unit Price
10+
$14.80
20+
$14.49
50+
$14.18
100+
$13.87
200+
$13.55
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Output Voltage
5V
Rated Current
0.6A
Power Rating
6W
Waterproof
Non-waterproof
Dimensions
1.25 x 0.79 x 0.48 in
Weight
0.03 lbs

Features

DIP 24 package with international standard pinout
4:1 wide input range
Low patient leakage current <5µA
Wide operating temperature range -40~+90℃
Medical safety approved(2xMOPP) according to IEC60601-1
Protections: Short circuit(Continuous)/Overload
6KVDC or 4.2KVAC high I/O isolation(Reinforced isolation)
3 years warranty

General Specification

Voltage accuracy ±2%
Efficiency 84%
Short circuit protection Continuous, automatic recovery
Working temperature -40°C to +90°C
Temp. Coefficient 0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm) 31.8*20.3*12.2mm (1.25*0.8*0.48 inch)
