Features:
- AC input range selectable by switch
- Withstand 300VAC surge input for 5 second
- Up to 200% peak power capability
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Compliance to IEC/BS EN/EN61558-1 and 62368-1
- Withstand 5G vibration test
- LED indicator for power ON
- No load power consumption<1W
- Overvoltage category III(OVC III)
- High operating temperature up to 70℃
- Operating altitude up to 2000 meters
- High efficiency, long life, and high reliability
- 3 years warranty
General Specification
AC input voltage range
90 ~ 132VAC / 180 ~ 264VAC by switch 240 ~ 370VDC (switch on 230VAC)
AC inrush current (max.)
COLD STAR 60A/115VAC 60A/230VAC
Overload protection
Output power >105% rated for more than 5 seconds then shut down o/p voltage, re-power on to recover
Output power >200% rated, hiccup mode, recovers automatically after fault condition is removed
Over-voltage protection
| 13.8 ~16.2V | 28.8 ~ 33.6V | 41.4 ~ 46.8V | 55.2 ~ 64.8V |
Shut down and latch off o/p voltage, and re-power on to recover
Over temperature protection
Shut down and latch off o/p voltage, and re-power on to recover.
Withstand voltage
I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Working temperature
-25 ~ +70℃ (Refer to "Derating Curve")
Safety standards
IEC/UL 62368-1, BSMI CNS15598-1,EAC TP TC 004,BIS IS13252(Part1): 2010/IEC 60950-1: 2005(except for 48V); GB 4943.1, BS EN/EN61558-1, BS EN61558-2-16; Designed by BS/EN/EN62368-1, AS/NZS 61558.1/2.16, AS/NZS 62368.1
Dimension (LxWxH)
215x115x30mm
