ELG-200-C1050A-3Y

Name: ELG-200-C1050A-3Y
Brand: MEAN WELL
Price: 55.37 USD
Availability: OutOfStock

$55.37

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$52.60

20+

$51.49

50+

$50.39

100+

$49.28

200+

$48.17

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

200V

Rated Current

1.05A

Power Rating

199.5W

Waterproof

IP65

Dimensions

9.60 x 2.79 x 1.47 in

Weight

2.68 lbs

Features

Constant Current mode output

Metal housing design with functional ground

built-in active PFC function

No load / Standby power consumption < 0.5W

IP67 / IP65 rating for indoor or outdoor installations

Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off); Smart timer dimming; DALI

Typical lifetime > 50000 hours

5 years warranty

General Specification

input voltage range	100 ~ 305VAC \| 142 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
AC inrush current	COLD START 65A(twidth=680μs measured at 50% Ipeak)/230VAC; Per NEMA 410
Over voltage protection	Shut down o/p voltage, re-power on to recover
Withstand voltage	I/P-O/P:3.75KVAC \| I/P-FG:2.0KVAC \| O/P-FG:1.5KVAC
Working temperature	-40 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety standards	UL8750(type”HL”), CSA C22.2 No. 250.13-12;BS EN/EN/AS/NZS 61347-1,BS EN/EN/AS/NZS 61347-2-13 independent, BS EN/EN62384;GB19510.14,GB19510.1;EAC TP TC 004;BIS IS15885(for 700A only); IP65 or IP67;KC61347-1,KC61347-2-13 approved
EMC standards	EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, GB17743,GB17625.1
Dimension (LxWxH)	244 x 71 x 37.5 mm
Packing	1.22Kg; 12pcs / 15.2kg / 0.72CUFT
