CLG-150-20A

Name: CLG-150-20A
Brand: MEAN WELL
Price: 33.07 USD
Availability: OutOfStock

$33.07

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$31.42

20+

$30.76

50+

$30.09

100+

$29.43

200+

$28.77

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

20V

Rated Current

7.5A

Power Rating

150W

Waterproof

Non-waterproof

Dimensions

8.74 x 2.67 x 1.52 in

Weight

2.20 lbs

Features

Universal AC input / Full range (up to 295VAC)

Built-in active PFC function

High effficiency up to 89%

Protection: Short circuit / Over current / Over voltage / Over Temperature

Cooling by free air convection

IP67 design for indoor or outdoor installations

Class II power unit

Pass LPS

100% full load burn-in test

High Reliability

Suitable for LED lighting and moving sign applications

Compliance to worldwide safety regulations for lighting

Suitable for dry / damp / wet locations

3 years warranty

General Specification

Short Circuit protection Type	Hiccup mode, recovers automatically after fault condition is removed
Withstand voltage	I/P-O/P:3.75KVAC
Isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH
Working temperature	-30 ~ +70 ℃ (Refer to "Derating Curve")
Safety standards	UL879, UL8750, UL1310, EN/AS/NZS 61347-1, EN/AS/NZS 61347-2-13 independent, CAN/CSA C22.2 No. 223-M91(except for 48V), CSA C22.2 No. 250.0-08(except for 48V), CSA C22.2 No. 207-M89(except for 48V), ,J61347-1, J61347-2-13, GB19510.1,GB19510.14 FileName:CLG-60-SPEC2018-01-08S&E EAC TP TC 004, IP67 approved
Dimension (LxWxH) (mm)	222.26838.8mm (LWH)
Packing	1.0Kg; 12pcs/13Kg/0.58CUFT
