A302-1K7-B2
Manufacturer MEAN WELL

A302-1K7-B2

Availability: Out of stock
1500 W110 V21V–30V in

Request a Backorder

Submit your request and we will confirm lead time.

A302-1K7-B2
Quantity Prices (USD)
Quantity
Unit Price (USD)
1+
$344.14 USD
10+
$326.93 USD
20+
$320.05 USD
50+
$313.17 USD
100+
$306.28 USD
200+
$299.40 USD
All prices are displayed in USD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
21V~30V
Output Voltage
110V
Power Rating
1500W
Waterproof
Non-waterproof
Dimensions & Weight
17.91 x 8.26 x 3.34 in12.12 lbs

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

Features

12V or 24V DC input
Power ON-OFF switch
Input voltage range: -15% ~ +25%
Output voltage regulation ±10%
Protections: Input reverse polarity/Bat. low shutdown/Over voltage/ Overload/Over temperature/Output short
Output waveform: Modified sine wave
Cooling fan ON-OFF control
ON/OFF remote control(Optional)
Approvals: E13 / EAC / CE / UKCA
1 year warranty

General Specification

AC output voltage range 110V; 230V
AC output waveform Modified sine wave
Overload temperature 60±5℃ / 140±9°F
Overvoltage 125~133% load
Output short Shut-off
Working temperature 0 ~ 30°C@ 100% load, 40°C@ 70% load
Safety standards EAC TP TC 004 approved
EMC standards IEC61000-4-2,3, EAC TP TC 020
Dimension (LxWxH) 455*210*85mm
Packing 3pcs / 19.6kg

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
