A301-150-B2
Manufacturer MEAN WELL

A301-150-B2

Availability: Out of stock
150 W110 V10V–15V in

Request a Backorder

Submit your request and we will confirm lead time.

A301-150-B2 SKU: 327-6489
Quantity Prices (USD)
Quantity
Unit Price (USD)
1+
$46.84 USD
10+
$44.50 USD
20+
$43.56 USD
50+
$42.62 USD
100+
$41.69 USD
200+
$40.75 USD
All prices are displayed in USD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
10V~15V
Output Voltage
110V
Power Rating
150W
Waterproof
Non-waterproof
Dimensions & Weight
4.80 x 2.87 x 1.77 in1.10 lbs

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

Features

12V or 24V DC input
Power ON-OFF switch
Input voltage range: -15% ~ +25%
Output voltage regulation ±10%
Protections: Input reverse polarity/Bat. low shutdown/Over voltage/ Overload/Over temperature/Output short
Output waveform: Modified sine wave
Topology: Microprocessor
Approvals: E13 / EAC / CE / UKCA
1 year warranty

General Specification

AC output voltage range 110V
AC output waveform Modified sine wave
Overload temperature 60±5°C / 140±9°F
Overvoltage 125~142% load
Output short Shut-off; Broken
Working temperature 0~+30°C@100% load, 40°C@50% load
Safety standards EAC TP TC 004 approved
EMC standards IEC61000-4-2,3, EAC TP TC 020
Dimension (LxWxH) 122*73*45mm
Packing 30pcs / 17Kg

SKU: 327-6489

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
