MPQ-200C

Name: MPQ-200C
Brand: MEAN WELL
Price: 94.11 USD
Availability: OutOfStock

$94.11

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$89.40

20+

$87.52

50+

$85.64

100+

$83.76

200+

$81.88

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

Rated Current

12A

Power Rating

200W

Waterproof

Non-waterproof

Dimensions

7 x 4.22 x 1.39 in

Weight

1.45 lbs

Features

Universal AC input/Full range

Low leakage current < 150μA

Protections: Short circuit/Overload/Over voltage/Over temperature

Free air convection for 140W and forced air convection for 200W

Medical safety approved(2 x MOPP between primary to secondary)

With power good and fail signal output

Built-in remote ON-OFF control

Built-in remote sense function

Fixed switching frequency at 100KHz

3 years warranty

General Specification

AC input voltage range	90~264VAC; 127~370VDC
AC inrush current	Cold start 40A
Leakage current	<150 μA/264VAC
Overload protection	120 ~ 160% rated output power
Over voltage protection	115%~135% rated output voltage
Setup, rise, hold up time	1000ms, 20ms, 16ms
Withstand voltage	I/P-O/P:4KVAC, I/P-FG:2KVAC, O/P-FG:1.5KVAC
Working temperature	-20~+70°C
Vibration	10~500Hz, 2G 10min./1cycle, period for 60min. Each along X, Y, Z axes
Safety standards	IEC60601-1, BS EN/EN60601-1
EMC standards	EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection	Input: JST B3P-VH, Output: JST B8P-VH
Dimension (LxWxH)	177.8x107.2x35.5
Packing	24pcs / 16.8kg
