EPP-500-18

Name: EPP-500-18
Brand: MEAN WELL
Price: 96.19 USD
Availability: OutOfStock

$96.19

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$91.38

20+

$89.46

50+

$87.53

100+

$85.61

200+

$83.69

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

18V

Rated Current

17.8A

Power Rating

320.4W

Waterproof

Non-waterproof

Dimensions

5 x 3 x 1.61 in

Weight

1.01 lbs

Features

5"x3" compact size

320W convection, 500W force air
550W peak power (3sec)

EMI for both Class I & Class II configuration

-30~+70℃ wide range operating temperature

No load power consumption<0.5W by PS ON control

High efficiency up to 94%

Protections: Short circuit/Overload/Over voltage/Over temperature

5Vdc standby output, 12Vdc fan supply, Power Good, Power Fail and remote sense

Operating altitude up to 5000 meters (Note.5)

LED indicator for power on

3 years warranty

General Specification

AC input voltage range	80 ~ 264VAC; 113 ~ 370VDC
AC inrush current	COLD START 40A/115VAC
Leakage current	<0.75mA / 240VAC
Overload protection	105 ~ 135% rated output power
Over-voltage protection	110%~130% rated output voltage
Setup, rise, hold up time	1000ms, 30ms, 10ms
Withstand voltage	I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC
Working temperature	-30~+70°C
Vibration	10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Safety standards	UL62368-1, TUV BS EN/EN62368-1, BS EN/EN60335-1, IEC62368-1, EAC TP TC 004 approved
EMC standards	UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
Connection	I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH
Dimension (LxWxH)	127x76.2x41
Packing	30pcs / 14.8kg
